MIL-DTL-1222J
Dimensional examination requirements.
TABLE XIV.
Type Fastener
Dimension to be examined
Major diameter
Go maximum material (Functional size)
Minimum material (Pitch diameter)
Head height
Width across flats
Bolts and Screws
(Except: Socket head cap
Width across corners
Shank diameter
screws)
Overall length
Thread length
Fillet radius
Straightness
Major diameter
Go maximum material (Functional size)
Minimum material (Pitch diameter)
Shank diameter
Studs
Overall length
Thread length
Straightness
Major diameter
Go maximum material (Functional size)
Minimum material (Pitch diameter)
Head height
Head diameter
Hex socket size
Key Engagement
Socket head cap screws
Width across flats
Width across corners
Shank diameter
Overall length
Thread length
Fillet radius
Straightness
Minor diameter
Go maximum material (Functional size)
Minimum material (Pitch diameter)
Nuts
Thickness
Width across flats
Width across corners
